What a Dubai villa network actually delivers when you do it right.

We have seen the same three failure patterns walk in the door every quarter, AED 80,000 to AED 300,000 each to put right. A Dubai Hills Fairway villa where the builder dropped Cat 5e behind every wall plate, the owner bought four Wi-Fi 7 access points, and the 2.5 GbE uplinks negotiated down to 100 megabit because Cat 5e cannot carry the channel. The drywall came down, the cable got ripped, Belden 10GX13 Cat 6A went back in. A Tilal Al Ghaf Elysian villa where an AV integrator buried six UniFi U6-Pro access points inside plaster ceilings, no airgap, no service loop, the radios cooked at 50 Celsius through August and dropped clients every six minutes. We pulled them, fitted UniFi U7 Pro Max with a 50 mm radome airgap, ran an Ekahau Sidekick 2 walk-test, and signed the heat-map. A District One villa on a single VLAN where a cheap Zigbee plug on the kids’ network reached the family-office laptop in 90 seconds, Hue, Lutron and the Hikvision NVR all crashed at the same time on a Friday afternoon.

We rebuild the network one installer deep. Belden 10GX13 Cat 6A and Corning SMF-28e+ OS2 fibre to every room. A UniFi UDM Pro Max gateway, a UniFi Pro Max 48 PoE switch, six to nine UniFi U7 Pro Max or Ruckus R770 Wi-Fi 7 access points on a heat-map signed by the owner. A Peplink Balance 380X with Etisalat fibre primary and du fibre or 5G secondary, sub six second failover. Seven VLANs published on the rack door. A Palo Alto PA-440 firewall when the home office runs the family CFO. Auvik and Domotz on every device, Synology DS1823xs+ for backup, APC Smart-UPS SRT 3000VA on the rack. From AED 18,000 single-villa starter to AED 2.5M Emirates Hills compound flagship.

One Tap, Whole Network

One controller. One handover folder. One phone number that picks up. Cat 6A and OS2 to every room, Wi-Fi 7 on a signed heat-map, seven VLANs, dual-WAN failover, 24/7 monitoring.

key benefits:

Auvik and Domotz polling every gateway, switch, access point and NAS every 60 seconds.
A signed Ekahau Sidekick 2 walk-test on day one and again on day thirty.
Fluke DSX-8000 channel-test PDF for every Cat 6A drop, Viavi MTS-2000 OTDR trace for every fibre strand.
Seven VLANs published on the rack door, Palo Alto PA-440 or UniFi UDM Pro Max at the gateway.

Speak with an expert

A Day At Your Villa

“Morning Zoom from the home office, no jitter, no drop.”

“Mid-morning, gate camera review on the iPad, two seconds to live.”

“Lunchtime Hue firmware update, IoT VLAN only, nothing else flickers.”

VLAN isolation holding, IoT and Cameras blocked from Mgmt

“Afternoon, three Plex 4K streams in three rooms, no buffer.”

“Evening, Crestron handoff to the cinema, one tap, audio on the AV VLAN.”

Etisalat dropped, Peplink failed over to du in 4.8 seconds

“Midnight, Synology snapshot to Backblaze B2, encrypted, UAE-resident.”

One tap, whole network

Failover under six seconds

Walk-test signed on day one and day thirty

Smart Network

"Etisalat dropped at 14:32, Peplink switched to du in 4.8 seconds, Auvik logged it, the Zoom call never blinked."

Book a free site survey

Rated 4.97/5 by Dubai Homeowners

Nine layers of villa networking.

One Tap, Whole Network. Cat 6A and OS2 to every room, Wi-Fi 7 on a signed heat-map, seven VLANs, dual-WAN failover, 24/7 monitoring. Built for villas in Dubai Hills and Tilal Al Ghaf, compounds in Emirates Hills and Al Barari, towers in Bluewaters and Downtown.

Structured Cat 6A & OS2 Fibre

Belden 10GX13 Cat 6A U/FTP plenum-rated CMP copper, blue jacket, 500 MHz channel-tested to TIA-568.2-D on a Fluke DSX-8000. Corning SMF-28e+ Ultra OS2 single-mode fibre between basement, ground, first floor and roof racks, twelve-strand armoured riser, every strand traced bidirectionally on a Viavi MTS-2000 OTDR at 1310 and 1550 nm. Panduit Mini-Com TX6A keystones, Panduit Net-Access patch panel, Corning EDGE8 LC/UPC for fibre. PDF per drop into the handover folder. Compound No Objection Certificate filed in your name.

Wi-Fi 7 Heat-Map Design

Six to nine UniFi U7 Pro Max or Ruckus R770 access points on a predictive heat-map drawn in Ekahau AI Pro 11.x, then signed off in person on day one with an Ekahau Sidekick 2 walk-test. We hold every primary room to minus 65 dBm or better, every doorway to minus 70 dBm. Wi-Fi 7 runs at 240 MHz channel widths under the current TDRA spectrum allocation. Walk-test target of 1.4 to 1.8 Gbps wireless on 6 GHz at 5 metres line of sight in a Tilal Al Ghaf or Dubai Hills villa.

VLAN Segmentation

Seven VLANs published on the rack door. Mgmt, IoT, AV, Guest, Cameras, Voice and Untrust. A cheap Zigbee plug on the kids’ VLAN cannot reach the family-office laptop on the management VLAN. Lutron, Hue and Sonos sit on the AV VLAN with mDNS reflection across to trusted. Hikvision and UniFi Protect cameras sit on VLAN 50 with PoE++ from a UniFi Pro Max 48 PoE switch. Geo-blocking inbound for high-risk regions. IDS and IPS in detect-and-block mode with weekly signature updates on the UniFi UDM Pro Max gateway.

Dual-WAN ISP Failover

A Peplink Balance 380X dual-WAN router with Etisalat e& 10G HomePro fibre on WAN1 and du Home 10G fibre on WAN2, or a Peplink MAX BR1 Pro 5G as the cellular secondary on a du 5G Home or e& 5G Home SIM. Sub six second cut-over when Etisalat trunk fibre cuts on a Friday afternoon, which it does on Palm Jumeirah and Emirates Hills more often than the buyer expects. SpeedFusion bonds both WANs for the morning Zoom call. The 10G HomePro plan currently sits in the AED 1,500 to AED 1,900 monthly band.

Family-Office Firewall

A Palo Alto PA-440 or PA-460 firewall with Threat Prevention, URL Filtering, WildFire and DNS Security subscriptions when the home office hosts the family CFO or a DIFC-licensed entity. Fortinet FortiGate 70F or 100F as the alternative stack. UniFi UDM Pro Max with built-in IDS and IPS for the standard Dubai Hills or Arabian Ranches III villa. MFA on every admin interface, encrypted backups, vendor patch management on a written cadence. ISO 27001-aligned hardening for the principal in DIFC or ADGM.

24/7 RMM Monitoring

Auvik as the primary remote monitoring and management platform, Domotz as the secondary client-facing portal with Apple Watch alerts. Both poll every gateway, switch, access point and NAS every 60 seconds. Any device offline more than five minutes auto-tickets into the DSH NOC inbox and an L2 engineer phones the owner inside the hour. Daily config dump to a Wasabi or AWS me-central-1 bucket plus the DSH cloud, encrypted at rest, UAE-resident where possible. From AED 850 a month for a tier-1 villa to AED 12,000 for a Palm Jumeirah Frond compound.

Smart-Home + AV Network Integration

Lutron Caseta Pro, RadioRA 3 or HomeWorks QSX bridges always wired Ethernet, never Wi-Fi. Crestron MC4-R, Control4 EA-5 or Savant Pro Host on the AV VLAN. Sonos Era 100, Era 300, Port and Amp on the AV VLAN with mDNS reflection. Philips Hue Bridge v2 wired Ethernet on IoT VLAN. Apple TV 4K as the primary HomeKit hub. Kaleidescape Strato C on a 10 GbE drop to the cinema rack. Tailscale and Cloudflare Zero Trust for remote access without opening firewall ports. The cinema, the lighting, the network and the cameras live under one project.

TDRA + DEWA + DCD Compliance

TDRA Type Approval verified per access point, gateway, camera and 5G router before customs release at Jebel Ali. DEWA cable-tray No Objection Certificate filed before the riser is drilled, MEP consultant of record signs off. Dubai Civil Defence FLSCOP 2018 plenum-rated CMP cable through every return-air ceiling void. Hilti CP 606 fire-stop sealant and CP 651S collar at every slab penetration, photographed and logged into the handover folder. MOIAT ECAS Certificate of Conformity at customs against UAE.S GSO 2530 and GSO 1956. Trakhees CD on Palm Jumeirah and Maritime City.

Backup + DR + UAE PDPL

A Synology DS923+ four-bay tower for the standard Dubai Hills villa, a Synology DS1823xs+ eight-bay flagship for a Palm Jumeirah Frond villa carrying CCTV plus media plus document backup on one unit. WD Red Pro CMR or Seagate Exos drives, never SMR. Backblaze B2 as the default cloud target, encrypted, S3-compatible. A Datto SIRIS BCDR appliance for family-office grade. UAE PDPL retention schedule on every NAS storing camera footage, door-lock logs or staff records. Cloud destinations default to AWS me-central-1 or Azure UAE North where the data crosses the wire.

Our Working Approach

How we wire your villa.

A team that surveys every floor, predicts the heat-map, files your compound NOC and DEWA tray NOC, and certifies every drop on a Fluke before a single AP is mounted.

We start with two engineers on site for two to three days. A senior network designer and a structured cabling lead. Day one morning, a predictive heat-map on Ekahau AI Pro 11.x, a walk-test with the Ekahau Sidekick 2 capturing 2.4, 5 and 6 GHz bands at 1, 4, 16 and 80 MHz channel widths in one pass, scan points every three metres. RF interference scan with a MetaGeek Wi-Spy DBx and Chanalyzer 6, twenty minutes per floor. Day one afternoon, a Hilti PS 50 ferroscan on every post-tension slab in Marina, JBR, Bluewaters, Downtown, Business Bay or Dubai Creek Harbour. Baseline tests on developer cabling with a Fluke DSX-8000 and a Viavi MTS-2000 OTDR. Bosch GLM 50-27 CG measures every cable run.

Then we design the network. A 32 to 38 page PDF design pack signed by the lead network engineer, sign-off averages five to nine days. Cat 6A run schedule with drop ID, room, height, run length plus ten percent slack, termination type, TIA-606-B label and VLAN. OS2 fibre backbone schedule. Access point heat-map signed off to minus 65 dBm in primary rooms, minus 70 dBm at doorways, minus 72 dBm in walk-in wardrobes and bathrooms. Core switch and gateway elevation. VLAN map, DNS filter design, failover design. UPS sizing on an APC Smart-UPS SRT 3000VA with a runtime calculation. Middle Atlantic MRK-2436 24U rack elevation drawn to scale.

Before site work begins we file the compound No Objection Certificate in your name. Emaar Community Management for Dubai Hills, Arabian Ranches III and Emirates Living. My Nakheel for Palm Jumeirah, Jumeirah Park and Al Furjan. Damac Community Management for Damac Hills and Damac Lagoons. Meraas Customer Care for Bluewaters Bay and City Walk. Trakhees CD plus EHS for Palm fronds and Maritime City. Al Barari Estate Management for Seventh Heaven. In parallel we file the DEWA cable-tray NOC, pre-submit DCD plenum cable through DCD Smart Services, pull the TDRA Type Approval certificate from eservices.tdra.gov.ae per BOM line item, and attach the MOIAT ECAS Certificate of Conformity for customs at Jebel Ali.

On site, two cable pullers and one foreman land 18 to 26 drops per day in clean ceiling void. Belden 10GX13 Cat 6A and Corning SMF-28e+ OS2 fibre share a Panduit FiberRunner overhead tray. Hilti CP 606 sealant on every slab penetration. Every Cat 6A drop certified channel-end to channel-end on a Fluke DSX-8000, every fibre strand traced bidirectionally on a Viavi MTS-2000. Rack build with a UniFi UDM Pro Max gateway, a UniFi Pro Max 48 PoE switch, a Peplink Balance 380X dual-WAN router and an APC Smart-UPS SRT 3000VA. Auvik plus Domotz enrolled on every device. Day 30 return walk-test on the Ekahau Sidekick 2, no charge.

"The builder dropped Cat 5e behind every wall plate, our four Wi-Fi 7 access points negotiated down to 100 megabit, and we lived with 180 megabit in the master bedroom on a 10G HomePro line for nine months. Three rooms went from 180 megabit to 1.6 gigabit on Wi-Fi 7."

"Our AV integrator buried six UniFi U6-Pro access points inside plaster ceilings with no airgap and the radios cooked at fifty Celsius. DSH pulled them, fitted U7 Pro Max with a 50 mm radome airgap, ran an Ekahau walk-test, and signed the heat-map."

Wi-Fi 7 Verified

"A Zigbee plug on the kids’ network reached the family-office laptop in ninety seconds. DSH rebuilt the network on a UniFi UDM Pro Max with seven VLANs published on the rack door, Auvik and Domotz on every device, and a phone number that picks up at three in the morning."

100% TDRA Approved

"Our family office runs Cisco out of DIFC and the home network had to match. Palo Alto PA-440 firewall, Cisco Catalyst 9300X core switch, Ruckus R770 access points, NESA-IAS controls map in the handover folder, named L2 engineer on every alert."

"Etisalat trunk fibre cut on the Frond on a Friday. Our Peplink Balance 380X failed over to du fibre in 4.8 seconds. Auvik logged the cut, the engineer phoned inside the hour, the Zoom call from the home office never blinked."

Wi-Fi 7 Verified

100% TDRA Approved

Compare the difference

Why homeowners choose us.

Belden 10GX13 Cat 6A U/FTP plenum CMP, 500 MHz channel-tested, Corning SMF-28e+ OS2 fibre between floors

Six to nine UniFi U7 Pro Max or Ruckus R770 access points on a signed Ekahau Sidekick 2 walk-test, owner countersigns the heat-map

Seven VLANs published on the rack door, Mgmt, IoT, AV, Guest, Cameras, Voice and Untrust, IPS in detect-and-block

Peplink Balance 380X with Etisalat fibre on WAN1 and du fibre or 5G on WAN2, sub six second failover

Fluke DSX-8000 channel-test PDF per drop and Viavi MTS-2000 OTDR trace per fibre strand into the handover folder

TDRA Type Approval certificate verified per access point and gateway before customs release at Jebel Ali

Auvik and Domotz polling every device every 60 seconds, auto-ticket on any device offline more than five minutes

Palo Alto PA-440 firewall, Tailscale, Cloudflare Zero Trust, NESA-IAS-aligned controls map on handover

Starting price

From AED 18,000

AED 2,400

How it works

How to commission a Dubai villa Wi-Fi 7 plus 10G fibre plus VLAN plus dual-WAN failover network the TDRA, DEWA and DCD all approve.

Six steps we walk every Dubai Hills, Tilal Al Ghaf, Emirates Hills, Palm Jumeirah Frond and District One villa through, from the first heat-map walk to day thirty.

Site survey, predictive heat-map, DEWA tray NOC, compound NOC, DCD plenum confirmation.
Two engineers on site for two days. Ekahau AI Pro 11.x predictive heat-map and an Ekahau Sidekick 2 walk-test capturing 2.4, 5 and 6 GHz at 1, 4, 16 and 80 MHz channel widths. MetaGeek Wi-Spy DBx interference scan, twenty minutes per floor. Hilti PS 50 ferroscan on post-tension slabs in Marina, JBR or Bluewaters. Compound No Objection Certificate filed against Emaar, My Nakheel, Damac, Meraas, Trakhees, Sobha or Al Barari. DEWA cable-tray NOC filed. DCD plenum cable pre-submission through DCD Smart Services.
First-fix cabling, Cat 6A and OS2 during construction, plenum CMP, Hilti fire-stops.
Two cable pullers and one foreman land 18 to 26 drops per day in clean ceiling void. Belden 10GX13 Cat 6A U/FTP plenum CMP, blue jacket. Corning SMF-28e+ Ultra OS2 single-mode fibre, twelve-strand armoured riser cable. Both share a Panduit FiberRunner overhead tray where ceiling void allows, otherwise a fire-stopped riser shaft. Hilti CP 606 sealant around bundles up to 38 mm OD, Hilti CP 651S collar through fire-rated walls, photographed and logged. Both ends labelled TIA-606-B on a Brady BMP41 heat-shrink.
Cable certification, Fluke DSX-8000 channel-test PDF per outlet, Viavi MTS-2000 OTDR trace per fibre run.
Every Cat 6A drop certified channel-end to channel-end on a Fluke DSX-8000 with the Cat 6A channel adapter, tested to TIA-568.2-D at 500 MHz. NEXT, PSNEXT, ACR-F, return loss, propagation delay, delay skew. Pass criterion is two decibels of headroom on NEXT. Every OS2 fibre strand traced bidirectionally on a Viavi MTS-2000 OTDR at 1310 and 1550 nm. PDF per drop archived to the client portal under cabling/certifications/. No rack build until 100 percent of drops pass.
Rack build and active layer, UDM Pro Max gateway, Pro Max 48 PoE switch, Peplink Balance 380X, APC SRT UPS, seven VLANs.
Five-day site window. A Middle Atlantic MRK-2436 24U swing-frame rack levelled and bonded to the meter-room earth bar with a 10 mm strap. Panduit Mini-Com TX6A copper patch panels and Corning EDGE8 fibre panels mounted, drops punched down or spliced. UniFi UDM Pro Max gateway on the top shelf, UniFi Pro Max 48 PoE switch below, Peplink Balance 380X with WAN1 to Etisalat e& 10G HomePro and WAN2 to du Home 10G or a Peplink MAX BR1 Pro 5G. APC Smart-UPS SRT 3000VA bottom shelf.
Wi-Fi 7 install and walk-test, TDRA Type Approval per SKU, Ekahau Sidekick 2 walk-test, owner signs the heat-map.
Mount six to nine UniFi U7 Pro Max, Ruckus R770 or Cisco Catalyst 9166 access points with a 50 mm radome airgap, never plaster-buried. Adopt every AP on the UniFi Network Application self-hosted on the UDM Pro Max. Push the radio plan, 6 GHz primary at 240 MHz channel widths under current TDRA spectrum allocation, Multi-Link Operation enabled, BSS coloring on. Owner walks the rooms with the engineer and signs the Ekahau heat-map at minus 65 dBm in every primary room.
Dual-WAN, RMM, handover and a day thirty return tune.
Bridge the Etisalat ONT and the du ONT into bridge mode, configure Peplink failover to cut over inside six seconds. Install Auvik as the primary RMM and Domotz as the secondary client-facing portal, both polling every device every 60 seconds. Walk the owner through the dashboard. Hand over the rack key, the laminated rack diagram inside the rack door, the SLA, the escalation tree and the printed and digital handover folder. We return at week 18 for four hours, walk every room with the Ekahau Sidekick 2, retune the radio plan, no charge.

frequently asked questions

Networking and IT, answered plainly.

Thirty real questions from Dubai villa and apartment owners on Wi-Fi 7, Cat 6A cabling, VLAN segmentation, dual-WAN failover, TDRA approval and 24/7 monitoring. Last Updated: April 2026.

How much does smart villa networking cost in Dubai?

A two- to four-bed JVC, Arabian Ranches 1 or The Springs villa starts from AED 18,000 on a UniFi Cloud Gateway Max, two UniFi U7 Pro access points and three VLANs, with TDRA Type Approval verified per radio before customs release. A full Dubai Hills, Tilal Al Ghaf or Jumeirah Golf Estates structured villa runs AED 60,000 to AED 180,000. An Emirates Hills, Palm Jumeirah Frond or District One signature villa lands AED 200,000 to AED 600,000 with a Palo Alto PA-440 firewall. Compound flagships at Al Barari Seventh Heaven reach AED 2.5M.

Do I need TDRA approval for a UniFi or Ruckus access point in Dubai?

Yes. Every Wi-Fi access point, gateway, IP camera and 5G router powered up in the UAE needs a TDRA Type Approval certificate before customs release. We pull the certificate from eservices.tdra.gov.ae per BOM line item and file it as {model}_{tdra_cert_no}_{expiry}.pdf against the purchase order. UniFi U7 Pro Max, Ruckus R770 and Cisco Catalyst 9166 are all TDRA Type Approval verified for Low Power Indoor 6 GHz at our supply date. Grey-market US-spec gear holds at Jebel Ali at AED 250 per day storage and gets pulled at the next compound audit in Emirates Hills.

Why does my builder's Cat 5e wiring not support Wi-Fi 7?

A UniFi U7 Pro Max access point uplinks at 2.5 GbE PoE+ to deliver Wi-Fi 7 at 240 MHz channel widths under current TDRA spectrum allocation. Cat 5e is rated to 100 MHz and 1 GbE, so a 2.5 GbE port negotiates down to 100 megabit on a Cat 5e drop. We have seen this in Dubai Hills Fairway villas where the owner paid for a 10G HomePro line and received 180 megabit in the master bedroom. Belden 10GX13 Cat 6A U/FTP, channel-tested on a Fluke DSX-8000 to TIA-568.2-D at 500 MHz, carries the channel.

How do I segment a smart home with Lutron, Hue, Sonos and cameras?

Seven VLANs published on the rack door. Mgmt for the UniFi UDM Pro Max gateway. IoT for the Philips Hue Bridge and Lutron Caseta Pro Smart Bridge Pro 2. AV for Sonos Era 300, Crestron MC4-R and Apple TV 4K with mDNS reflection across to trusted. Guest, internet only, no inter-VLAN. Cameras on VLAN 50 with PoE++ from a UniFi Pro Max 48 PoE switch. Voice for SIP. Untrust for the contractor at the gate. A District One villa we rebuilt last year had everything on one flat /24 and the kids' Zigbee plug reached the family-office laptop in ninety seconds.

Etisalat e& 10G HomePro versus du 10G, which for a Dubai villa?

Both. We run Etisalat e& 10G HomePro on a Nokia 7368 ISAM ONT in bridge mode as WAN1, and du Home 10G on a Nokia XS-010X-Q ONT in bridge mode as WAN2 into a Peplink Balance 380X. Etisalat covers Palm Jumeirah, Emirates Hills and most of Dubai Hills with stronger SLA on the trunk. du covers Tilal Al Ghaf, Jumeirah Park and Al Furjan with comparable XGS-PON. The 10G HomePro plan currently sits in the AED 1,500 to AED 1,900 monthly band. Sub six second failover when the trunk cuts on a Friday afternoon, which it does.

Do you do 24/7 monitoring of a Dubai villa network?

Yes. Auvik as the primary remote monitoring and management platform, Domotz as the secondary with Apple Watch alerts for the owner. Both poll every gateway, switch, access point and NAS every 60 seconds over SNMP and syslog. Any device offline more than five minutes auto-tickets into the DSH NOC inbox and a named L2 engineer phones the owner inside the hour. Daily config dump to a Wasabi or AWS me-central-1 bucket. From AED 850 a month for a JVC tier-1 villa to AED 12,000 a month for a Palm Jumeirah Frond compound with a 2-hour on-site SLA.

What does the handover folder include?

Printed and digital. Cat 6A run schedule with TIA-606-B labels, OS2 fibre backbone schedule, signed Ekahau Sidekick 2 heat-map at minus 65 dBm in every primary room, VLAN map, rack elevation, Fluke DSX-8000 channel-test PDF per drop, Viavi MTS-2000 OTDR trace per fibre strand, TDRA Type Approval certificate per access point, MOIAT ECAS Certificate of Conformity, DEWA cable-tray No Objection Certificate, DCD plenum stamp, compound No Objection Certificate from Emaar, My Nakheel, Damac, Meraas, Trakhees or Al Barari, NESA-IAS-aligned controls map, UAE PDPL retention schedule, escalation tree, rack key, laminated rack diagram inside the rack door.

What happens when Etisalat goes down at the villa?

A Peplink Balance 380X cuts over to the secondary WAN inside six seconds. WAN2 is du Home 10G fibre on a Nokia XS-010X-Q ONT in bridge mode where dual fibre is available, otherwise a Peplink MAX BR1 Pro 5G on a du 5G Home or e& 5G Home SIM. SpeedFusion bonds both WANs for the morning Zoom call. Auvik logs the cut, the named L2 engineer phones inside the hour. We saw a Palm Jumeirah Frond trunk fibre cut at 14:32 on a Friday last quarter, the failover landed at 4.8 seconds, the owner's call never blinked.

How do you handle the compound No Objection Certificate?

We file it in your name. Emaar Community Management for Dubai Hills, Arabian Ranches III and Emirates Living, 7 to 14 days at AED 1,500 to AED 3,500. My Nakheel for Palm Jumeirah, Jumeirah Park and Al Furjan, 5 to 10 days at AED 1,000 to AED 2,500. Damac Community Management for Damac Hills and Damac Lagoons. Meraas Customer Care for Bluewaters Bay and City Walk. Trakhees CD plus EHS for Palm fronds and Maritime City, 14 to 28 days. Al Barari Estate Management for Seventh Heaven. Filed in parallel with the DEWA cable-tray NOC and DCD pre-submission.

Is the DSH network aligned to UAE Cybersecurity Council and PDPL?

Yes. We map the controls to UAE Information Assurance Standards (NESA IAS v1.1) and hand the matrix over in your folder. T1.3.1 VLAN segmentation for owners, staff, guests, IoT and CCTV. T1.4 WPA3-Enterprise on owner SSIDs where supported, WPA3-Personal otherwise. T7 central syslog retained 90 days minimum. T13 incident call tree. UAE PDPL retention on the Synology DS923+ or DS1823xs+. CCTV at 30 days indoors, 31 days at the gate. Cloud backup defaults to AWS me-central-1 or Azure UAE North. We do not claim NESA-certified, we say NESA-IAS-aligned controls map on handover.

How does Wi-Fi 7 actually perform inside a Dubai villa?

Wi-Fi 7 runs at 240 MHz channel widths on 6 GHz under the current TDRA spectrum allocation, with the upgrade path to 320 MHz when TDRA opens U-NII-6 and AFC for residential gear. A UniFi U7 Pro Max access point delivers a real-world walk-test of 1.4 to 1.8 gigabit at five metres line of sight on 6 GHz, and Multi-Link Operation across 5 GHz and 6 GHz holds throughput when the client roams between rooms in a Tilal Al Ghaf Elysian villa. We hold every primary room to minus 65 dBm or better on a signed Ekahau Sidekick 2 walk-test.

Why a Peplink Balance 380X instead of the Etisalat router?

The Etisalat e& Home Pro router is fine inside one apartment. In a 6,000 to 25,000 square foot Dubai Hills, Emirates Hills or Palm Jumeirah Frond villa it cannot route at line rate, hold a stable VLAN trunk, or fail over to a second WAN. A Peplink Balance 380X carries dual XGS-PON WANs, SpeedFusion bonding, sub six second failover, and 24/7 InControl 2 monitoring that hands telemetry into Auvik. We bridge the Nokia 7368 ISAM ONT from Etisalat and the Nokia XS-010X-Q from du, both in bridge mode, into the Peplink WAN ports.

Why does VLAN segmentation matter for a smart home?

A flat /24 lets a cheap Zigbee plug on the kids' network reach the family-office laptop on the same broadcast domain. We saw an Address Sky View penthouse last quarter where Hue, Lutron and a Hikvision recorder all crashed on a Friday afternoon because of a single rogue device. Seven VLANs on the UniFi UDM Pro Max published on the rack door, Mgmt 10, IoT 20, AV 30, Guest 40, Cameras 50, Voice 60, Untrust 99. The Lutron RadioRA 3 bridge wired to AV, Philips Hue Bridge wired to IoT, UniFi Protect cameras on VLAN 50.

What firewall do you put on a family-office home network?

A Palo Alto PA-440 for the standard signature villa, or a PA-460 when the home office hosts the family CFO of a DIFC- or ADGM-licensed entity. Threat Prevention, URL Filtering, WildFire and DNS Security subscriptions are mandatory at this tier. Fortinet FortiGate 70F or 100F as the alternative stack. UniFi UDM Pro Max with built-in IDS and IPS for the standard Dubai Hills or Arabian Ranches III villa. We saw an Emirates Hills Sector W villa last quarter where a PA-440 with a NESA-IAS-aligned control map was the close trigger from the family CIO.

How do you stop a smart-home device sending data to a random country?

Geo-blocking inbound and outbound on the UniFi UDM Pro Max or the Palo Alto PA-440 firewall, with high-risk regions blocked by default and the client adding extras. DNS rewriting on outbound port 53 forces Sonos Era 300, Apple TV 4K and IoT hubs that hard-code 8.8.8.8 onto a Pi-hole 6 redundant pair on Raspberry Pi 5 with Cloudflare 1.1.1.3 upstream for the parents and NextDNS family profile upstream for the kids. A Tilal Al Ghaf villa we rebuilt had a Hikvision camera phoning home over port 9000 that we blocked at the firewall.

Can I get Cisco Catalyst gear at home if my office runs Cisco?

Yes. We deploy a Cisco Catalyst 9300-48P or a Catalyst 9300X-48HX core switch with UPOE+ at 90 watts per port and 25 GbE downlinks when the family office IT firm dictates a Cisco stack. Cisco Catalyst 9166 and 9166D1 access points adopt to a Cisco Catalyst Center, the 2024-onwards rebrand of Cisco DNA Center, for fabric management. A Cisco Meraki MX95 or MX105 firewall on the e& 10G HomePro WAN. Through GBM as the channel. We have run this stack at Emirates Hills sectors V and W and at a District One mansion in MBR City.

Do you support Tailscale or Cloudflare Zero Trust for remote access?

Both, and a third. Tailscale as the default mesh VPN over WireGuard, with the subnet router running on the UniFi UDM Pro Max as a Docker container or on a dedicated Raspberry Pi 5. Cloudflare Zero Trust plus Cloudflare Tunnel for inbound Plex, Home Assistant or Synology UI access without opening firewall ports. UniFi Identity Enterprise WireGuard when the client wants everything inside the UniFi dashboard. The Arabian Ranches III villa owner who lives between Dubai and London logs in to the home Plex from a Heathrow lounge over Tailscale on a phone.

How does the family office NAS handle UAE PDPL?

A Synology DS923+ four-bay tower for the standard Dubai Hills villa, a Synology DS1823xs+ eight-bay flagship for a Palm Jumeirah Frond villa carrying CCTV plus media plus document backup. WD Red Pro CMR or Seagate Exos drives, never SMR. We set a UAE PDPL retention schedule per share. CCTV indoors at 30 days, gate cameras at 31 days, door-lock logs at 90 days, utility-bill scans at 7 years. Backblaze B2 as the cloud target, encrypted at rest and in transit, with AWS me-central-1 or Azure UAE North as the in-region alternative for personal data of staff.

What does 24/7 RMM monitoring actually cover?

Auvik polls every gateway, switch, access point, NAS, UPS and PDU on the rack every 60 seconds over SNMP and syslog. Domotz mirrors the same telemetry into a client-facing portal with Apple Watch alerts for the owner. Auto-ticket on any device offline more than five minutes, on UPS battery threshold, on switch port flap, on AP client drop above ten percent, on WAN failover, on firewall threat-prevention hit. Daily config dump on the UniFi UDM Pro Max to Wasabi or AWS me-central-1. Monthly executive summary as a one-page PDF for the family office in Emirates Hills.

Why do you mount access points with a 50 mm airgap?

Because Dubai ceiling voids run at 45 to 50 Celsius through July and August. A UniFi U7 Pro Max plaster-buried with no airgap thermally throttles its 6 GHz radio inside fifteen minutes, drops clients every six minutes, and shortens the radome lifespan from seven years to three. We have pulled six U6-Pro access points out of plaster ceilings in a Tilal Al Ghaf Elysian villa where an AV integrator wanted them invisible. We mount with a 50 mm radome airgap on a steel ceiling box, run a service loop, and the same access point holds line-rate through August.

How long does a Dubai villa network install actually take?

Fourteen to sixteen weeks from signed quote to handover on a mid-tier 6,500 square foot, 36-drop, nine-AP, single-rack, dual-ISP villa in Dubai Hills or Tilal Al Ghaf. Site survey on day one to three. Design pack at week two to three. TDRA Type Approval verification, DEWA cable-tray NOC and compound NOC at week two to seven. First-fix cabling at week seven to nine. Cable certification at week nine to ten. Rack build at week ten to twelve. Wi-Fi commissioning at week twelve to thirteen. VLAN, firewall and RMM at week thirteen to fourteen. Day thirty return walk-test, no charge.

What does the site survey involve?

Two engineers on site for two to three days. A senior network designer and a structured cabling lead. Day one morning, an Ekahau AI Pro 11.x predictive heat-map and an Ekahau Sidekick 2 walk-test capturing 2.4, 5 and 6 GHz at 1, 4, 16 and 80 MHz channel widths in one pass, scan points every three metres. RF interference scan with a MetaGeek Wi-Spy DBx and Chanalyzer 6, twenty minutes per floor. Day one afternoon, a Hilti PS 50 ferroscan on every post-tension slab in Marina, JBR or Bluewaters. Baseline tests on developer cabling with a Fluke DSX-8000 and a Viavi MTS-2000 OTDR.

Can you do this during construction or only after handover?

Both. First-fix cabling during construction is the cheaper path. Belden 10GX13 Cat 6A and Corning SMF-28e+ OS2 fibre go in before the plasterer arrives, sharing a Panduit FiberRunner overhead tray, with Hilti CP 606 fire-stop sealant on every slab penetration photographed and logged. Retrofit after handover is more common. Most Dubai Hills Fairway, Tilal Al Ghaf and Arabian Ranches III villas were sold with builder Cat 5e behind every wall plate. We pull the existing cable, run new Cat 6A on a Fluke DSX-8000 channel test, and minimise drywall damage with a Bosch GLM 50-27 CG laser before any cut.

Do I need to be on site during the install?

For two moments. The day one heat-map walk-test where you sign off the access point positions on the Ekahau plan, and the handover where the lead engineer walks you through the dashboard, the rack key, the laminated rack diagram inside the rack door, the SLA and the escalation tree. Everything in between, including DEWA cable-tray NOC submission, MOIAT ECAS clearance at Jebel Ali, Emaar or My Nakheel compound NOC filing, Fluke DSX-8000 cable certification and rack build, runs without you. We send weekly photo updates from the foreman on a WhatsApp.

What happens if the developer-installed fibre is the wrong type?

We test it on day one and replace it. Some Dubai Hills villas were handed over with plastic optical fibre between floors instead of OS2 single-mode, which caps at 1 gigabit and cannot carry the 10 GbE backbone we need. We trace every strand on a Viavi MTS-2000 OTDR at 1310 and 1550 nm. If it fails the OS2 spec we pull Corning SMF-28e+ Ultra single-mode in a twelve-strand armoured riser cable through the existing conduit, splice on a Sumitomo Type-71C fusion splicer at under 0.05 dB loss, and certify bidirectionally. Splice loss goes into the handover folder.

How do you handle a compound that does not allow visible cable runs?

We design around it. A Panduit FiberRunner overhead tray inside the ceiling void where ceiling void allows. A fire-stopped riser shaft against the existing DEWA telecoms riser where the Dubai Building Code 2021 requires a dedicated 600 mm by 600 mm telecoms riser. Surface conduit only as the last resort, painted to match the wall, on the back side of the joinery. In Al Barari Seventh Heaven and Emirates Hills sectors V and W we file the compound No Objection Certificate against the architect-of-record stamp and route through joinery cavities to keep every plate flush with the marble.

What is the day thirty return tune?

At week eighteen we return on site for four hours. The senior network designer walks every room with the Ekahau Sidekick 2, captures a fresh walk-test against the family's actual room usage and device count, and retunes the radio plan. Channel and power per UniFi U7 Pro Max access point, Multi-Link Operation pairing per client, BSS coloring per SSID. We update the VLAN map if the client added a Tesla Wall Connector, a Sonos Era 300 or a Hikvision camera since handover. Updated heat-map and updated handover folder. No charge. Every Dubai Hills, Tilal Al Ghaf and Emirates Hills install gets one.

How does this network play with my Lutron, Crestron or Control4 setup?

Lutron Caseta Pro Smart Bridge Pro 2, RadioRA 3 main repeater or HomeWorks QSX HQP7 processor always wired Ethernet, never Wi-Fi, on the AV VLAN. Crestron MC4-R, Control4 EA-5 or Savant Pro Host on the AV VLAN with mDNS reflection across to trusted. Sonos Era 100, Era 300, Port and Amp on the AV VLAN. Apple TV 4K third generation as the primary HomeKit hub. Kaleidescape Strato C on a 10 GbE drop to the cinema rack from the UniFi Pro Max 48 PoE switch. We have run this exact stack at Palm Jumeirah Frond villas and Tilal Al Ghaf Lanai Islands.

What does the rack actually look like inside the closet?

A Middle Atlantic MRK-2436 24U swing-frame rack levelled and bonded to the meter-room earth bar with a 10 mm strap. Top shelf the UniFi UDM Pro Max gateway. Below it the UniFi Pro Max 48 PoE switch with 720 W of PoE budget. The Peplink Balance 380X dual-WAN router. The Synology DS1823xs+ NAS. The APC Smart-UPS SRT 3000VA bottom shelf. Patch cable colour code, blue data, yellow Mgmt, red Cameras, green AV, grey IoT. Inlet under 28 Celsius, outlet under 38 Celsius after a four-hour iperf3 load test. A Middle Atlantic FAN-RM-1 fan tray if outlet exceeds 40 Celsius.

What warranty and ongoing support do I get?

Twenty-five year cabling warranty on the Belden 10GX13 Cat 6A and Corning SMF-28e+ OS2 fibre system, registered with the manufacturer in your name. Three-year hardware warranty on UniFi, Ruckus and Cisco active gear, dealer-channel-routed through Almoe IT, Spectrami or GBM. Day thirty return walk-test on the Ekahau Sidekick 2, no charge. From AED 850 a month for tier-1 Auvik plus Domotz monitoring up to AED 12,000 a month for a Palm Jumeirah Frond compound with a 2-hour on-site SLA and a named L2 engineer. Annual penetration test by a UAE-licensed firm at family-office tier in Emirates Hills.

Let’s wire your villa.

A senior network designer and a structured cabling lead will walk every floor, run the predictive heat-map, scan the slab where it matters, and price the network honestly. No deposit, no paperwork yet.
